met[LOG] with met[APP] data logger

€685,00 EUR

met[LOG] with met[APP] data logger

met[LOG] with met[APP] data logger

14 in stock
€685,00 EUR
€685,00 EUR
Tax calculated at checkout. Shipping calculated at checkout.

SMART SERIAL SOLUTION

The met[LOG] data logger and the met[APP] browser app bring your weather data easily and quickly to your network (LAN). The met[LOG] features plug-and-play auto-configuration for easy setup of serial LAMBRECHT meteo sensors.

BROWSER APP MET[APP]

The met[LOG] browser app allows you to easily visualize current meteorological data in your network. It's platform-independent: on your laptop, tablet, or smartphone.

  • Display the current values ​​of your LAMBRECHT meteo station
  • Exporting the measured values ​​stored by metLOG]
  • Configuring the met[LOG]

Features and benefits:

  • Real-time access to the measurement data via the integrated web server, visualized in your browser with the met[APP]
  • Calculating trends and curves, performing automatic corrections of altitudes and air pressure
  • Warnings or alarm signals that can be set via digital outputs
  • Plug & Play: Auto-configuration at the touch of a button, enables full performance within seconds
  • Versatile combination options through 7 interfaces for connecting 4 analog and 3 serial sensors
Datasheet Brochure: Modbus Weather Solutions MetLog User Manual

APPLICATIONS

  • Building technology
  • Universities
  • industry
  • health resorts

Product details

Data sheet

Product Line

met[LOG] with met[APP]

Id-No.

00.95800.010000 (including SD card)

Measuring range

Voltage input: 0...10 V

Accuracy

Analog: 12 bit

Signal input

4 analog/digital inputs • Range: 0...10 V (configurable) • Ri ≥ 10 KΩ

Output

4 digital outputs • digital max. output voltage: V0-0.1 V up to V0 • max. 0.7 A

Protocols

Modbus · NMEA · WIMWV · WIMWD · WIMTA · WIMMB · WIMHU · WIXDR • rain[e]-Talker • SDI-12 on RS 485 (rain[e])

Interface

3 x RS 485 • A+, B-; half-duplex

Measurement intervals

1 sec · configurable

Operating conditions

-40...+85 °C

Supply voltage

11…32 VDC

Power consumption

500 mW typical (no digital output active)

Storage capacity

Accessories: 8 GB SD card, Ident No. 32.95800.010000 (included)

Storage interval

1 min · 2 min · 5 min · 10 min

Ethernet

10/100 BaseT • Shielded RJ45 connector

Dimensions

17.8 x 89 x 60 mm

measuring element

Areas of application

Housing

Measuring principle

Starting values

Data analysis

integrated website to display the current values • configuration webpage

Power consumption

Survival speed

Temperature ranges

Mean intervals

Extreme values

storage medium

Display

Operation

Data transfer

Data format

Protection class

Weight

62 kg

Standards and norms

EMC: IEC 61000-4-2 up to 8 kV

Included in delivery

Automatic configuration of the connected serial LAMBRECHT sensors: rain[e], EOLOS, WENTO, ARCO and THP sensors as well as all Modbus sensors from LAMBRECHT

Options (order separately)
  • 30.95800.015000: power[cube] 150W incl. met[LOG]
  • 30.95800.048000: power[cube] 480W incl. met[LOG]
  • 30.95800.115000: power[cube] WiFi Edition incl. met[LOG]

Example label

Value

Example label

Value

Example label

Value

Example label

Value

Example label

Value

Example label

Value

Example label

Value

Example label

Value

Example label

Value

Example label

Value

Example label

Value

Accessories

power[cube] Power Supply Unit

The compact cube is an all-weather-resistant power pack and rounds off for example the rain[e] station regarding power supply and communication. Beside the data logger met[LOG] it protects the net adapter (24 V/ 150 W) and the WiFi router against all weather influences.

  • Low space requirement
  • Easy installation
  • Very robust
  • Universal use for various sensors
  • Housing made from UV and weather-proof material
